4000L liquid storage tanks for sale
Stainless steel liquid Storage Tanks for sale, Here we sell various kinds of volume stainless steel liquid storage tanks
PRODUCT DESCRIPTION
Description
Stainless steel tanks are commonly used for water storage, liquid storage, milk storage, temporary material storage and more. They are widely applied in dairy, beverage, fruit juice, pharmaceutical, chemical and bio-engineering industries.
Single-layer storage tanks are extensively used in beverage, food, dairy, pharmaceutical, chemical and processing industries as liquid storage tanks, liquid mixing tanks, temporary storage tanks and water storage tanks. They can be cleaned to meet sanitary standards.
Have different kinds of agitators:
1, Bottom magnetic agitator with propeller impeller, speed from 50-400rpm or 50-800rpm. this kind of agitator is mixing thin viscosity , such as eyedrop, injection, CIP liquid, water, etc.
2, Top mechancial agitator with propeller impeller, speed at fix 71rpm or adjustable 20-200rpm or special requirement. this kind of agitator is mixing syrup, injection, blood, oral liquid, culture media, etc.
3, Top mechanical agitator with anchor or frame impeller, speed is from 10-70rpm. it is mixing higher viscosity , such as sediment or viscosity oral liquid, etc.
4, Top emusification homogenizer, speed max 2900rpm for small vessel, 1480rpm for bigger tank. this kind of agitator is mixing most high viscosity , such as suspension, oil, fat emulsification , etc.
5, Bottom emusification homogenizer, speed max 2900rpm for small vessel, 1480rpm for bigger tank. this kind of agitator is mixing most high viscosity , such as suspension, oil, fat emulsification , etc.
Features
Single-layer tanks are widely used in beverage, food, dairy, pharmaceutical, chemical and processing sectors. They can serve as mixing tanks, buffer tanks and storage tanks and comply with sanitary cleaning requirements.
Structural features: Constructed of single-layer, double-layer or three-layer stainless steel. All materials are food-grade clean stainless steel. Human-oriented structural design ensures easy operation. Aelt transitions are adopted for inner-wall joints of the tank to eliminate sanitary dead corners.
We supply single-layer and double-layer stainless steel tanks with capacities ranging from 50 L up to 100,000 L or even larger upon request.
Factory-price Sanitary Food-grade Liquid Water Storage Vessel, Custom Jacketed Insulated Stainless-steel Tank
Introduction / Types
Factory price sanitary food liquid water storing vessel customized drum jacketed insulated stainless steel tank |
Profile/type | Single layer tank | Double layer tank | Three layer tank |
material | SS304 or SS316L |
Volume | 50L-30T (Customized) |
Pressure | Vacuum-1Mpa |
Tank Type | Vertical type or Horizontal type |
Structure | one layer | Inner layer+jacket | inner layer+jacket+insulation |
Cooling way | No | ice water /cooling water | ice water /cooling water |
heating way | No | electric/steam heating | electric/steam heating |
Parts Details | 1.Quick open manhole / Pressure manhole |
2.Various types of CIP cleaners |
3.Sterile respirator |
4.Adjustable Legs |
5.Inlet and Outlet sanitary valve |
6.Thermometer (According to customer requirements ) |
7.Paddle blender .(According to customer requirements) |
8.Liquid level meter and lever controller (According to customer requirements) |
9.Ladder |
Advantages of Our Tanks
1. Made entirely of SS304 stainless steel
2. Excellent corrosion resistance and long service life
3. Small footprint and easy to move
4. Reliable sealing performance
5. High-precision polishing and attractive appearance
6. Polyurethane foam insulation layer and dimple-type heating jacket are optional
Dimension Data:
Effective volume
| (D*H) Dimension of tank | (H) Total height | Diameter of inlet& outlet |
(L) | (mm) | (mm) | (mm) |
500 | 840*1000 | 2250 | 38 |
600 | 920*1000 | 2300 | 38 |
700 | 990*1000 | 2300 | 38 |
800 | 950*1220 | 2500 | 38 |
900 | 1010*1220 | 2500 | 38 |
1000 | 1060*1500 | 2850 | 51 |
1500 | 1160*1500 | 2850 | 51 |
2000 | 1340*1500 | 2900 | 51 |
3000 | 1410*2000 | 3400 | 51 |
4000 | 1620*2000 | 3450 | 51 |
5000 | 1810*2000 | 3500 | 51 |
6000 | 1980*2000 | 3550 | 51 |
7000 | 1930*2440 | 4000 | 51 |
8000 | 2060*2440 | 4000 | 51 |
9000 | 2180*2440 | 4050 | 51 |
10000 | 2300*2440 | 4050 | 51 |
12000 | 2270*3000 | 4600 | 51 |
15000 | 2530*3000 | 4700 | 51 |
20000 | 2640*3660 | 5400 | 51
|
It also can be made according to special requirements of customers.
FAQ
Q: What about payment terms, payment security and lead time?
A: We accept 40% deposit, with balance paid before shipment. Irrevocable sight L/C is also acceptable. Lead time ranges from 7-30 days depending on order quantity.
Q: How do we confirm product specifications?
A: Our professional engineers handle all design and modification work according to your requirements. OEM and ODM services are available.
Q: What trade terms can you offer?
A: Accepted delivery terms: FOB, CFR, CIF, EXW, DDP, DDU, Express delivery. Accepted currencies: USD, EUR, CNY. Accepted payment methods: T/T, L/C, Credit Card, Western Union, Alipay.
Q: How can we verify that your machine works properly?
A: We will run full functional tests on the equipment before delivery.
Q: What is your minimum order quantity?
A: 1 set.
4000L Food Grade Stainless steel Storage Tank – Complete Industrial Guide for Food & Beverage
Processing
1. Introduction
A 4000L Food Grade Stainless Steel Storage Tank is a large-capacity industrial vessel widely used in food processing, beverage production, dairy manufacturing, fruit juice processing, sauce production, and liquid ingredient storage systems. It is designed to safely store large volumes of liquid food products under hygienic, controlled, and stable conditions.
In modern industrial food production, storage is not just a passive step. It is a critical control point that directly affects product quality, safety, taste, and shelf life. The 4000-liter stainless steel tank plays a key role in ensuring that liquids remain contamination-free, oxidation-resistant, and temperature-stable throughout production and packaging cycles.
Made from food-grade stainless steel (SS304 or SS316), this tank provides excellent corrosion resistance, durability, and compliance with international food safety standards such as FDA, HACCP, and GMP. It is engineered for continuous operation in demanding industrial environments where hygiene and efficiency are essential.
This comprehensive guide explains everything about the 4000L Food Grade Stainless Steel Storage Tank, including design structure, specifications, applications, working principles, advantages, maintenance systems, cleaning procedures, safety compliance, industry trends, and purchasing considerations.
2. What is a 4000L Food Grade Stainless Steel Storage Tank?
A 4000L SS Food Grade Storage Tank is a hygienic container designed for storing liquid or semi-liquid food products in a controlled environment. It is widely used as a buffer tank, storage tank, mixing tank, or temporary holding tank in food production lines.
Core Definition:
It is a sealed or semi-sealed stainless steel vessel with 4000-liter capacity, designed for sanitary storage of edible liquids while maintaining their quality, texture, and safety.
Main Functions:
·
Storage of processed liquid food products
·
·
Buffering between production stages
·
·
Maintaining temperature stability
·
·
Preventing contamination and oxidation
·
·
Ensuring continuous production flow
·
·
Supporting automated processing systems
·
Typical Products Stored:
·
Fruit juice and concentrates
·
·
Dairy products (milk, cream, yogurt base)
·
·
Sauces and condiments
·
·
Syrups and sweeteners
·
·
Edible oils and liquid ingredients
·
·
Beverage blends and functional drinks
·
3. Importance in Food and Beverage Industry
In modern food manufacturing systems, storage tanks are essential components of production efficiency and product safety.
Without proper storage systems, food liquids may suffer from:
·
Microbial contamination
·
·
Flavor deterioration
·
·
Color oxidation
·
·
Sedimentation or separation
·
·
Nutritional loss
·
·
Production inconsistency
·
The 4000L stainless steel storage tank solves these issues by providing:
·
A sealed hygienic environment
·
·
Stable temperature conditions
·
·
Controlled mixing and circulation
·
·
Smooth integration into production lines
·
·
Easy cleaning and sterilization
·
This makes it an essential asset for industrial-scale food production systems.
4. Key Features of 4000L SS Food Grade Storage Tank
4.1 Food Grade Stainless Steel Construction
The tank is manufactured using:
·
SS304: Standard food processing applications
·
·
SS316: High-corrosion or acidic product environments
·
Both materials offer:
·
High corrosion resistance
·
·
Non-toxic surface
·
·
Easy cleaning capability
·
·
Long service life
·
4.2 Hygienic Interior Design
·
Mirror-polished inner surface (Ra ≤ 0.4 μm optional)
·
·
No dead corners or residue traps
·
·
Fully drainable bottom structure
·
·
Welded seams polished for smooth finish
·
4.3 Temperature Control System
Optional jacket systems include:
·
Steam heating jacket
·
·
Electric heating system
·
·
Glycol cooling jacket
·
These systems ensure:
·
Stable product temperature
·
·
Prevention of fermentation
·
·
Preservation of flavor and nutrients
·
4.4 Agitation System
·
Low-speed food-grade agitator
·
·
Prevents sedimentation
·
·
Ensures uniform consistency
·
·
Suitable for viscous or pulpy liquids
·
4.5 Insulation Layer
·
PU foam insulation
·
·
Reduces energy loss
·
·
Maintains temperature stability
·
·
Improves energy efficiency
·
4.6 Sanitary Valves and Connections
·
Tri-clamp sanitary fittings
·
·
Butterfly or ball valves
·
·
Food-grade seals and gaskets
·
·
Easy integration into pipelines
·
5. Technical Specifications Table
Parameter
Specification
|
|
Capacity | 4000 Liters |
Material | SS304 / SS316 Stainless Steel |
Tank Type | Vertical / Horizontal Cylindrical |
Bottom Type | Conical / Sloped / Flat |
Diameter | 1800–2200 mm |
Height | 2000–2600 mm |
Surface Finish | Internal mirror polish / External brushed |
Insulation | PU foam optional |
Agitator | Low-speed motorized optional |
Jacket Type | Steam / Electric / Glycol |
Temperature Range | 0°C – 120°C |
Pressure | Atmospheric / Low pressure |
Cleaning System | CIP compatible |
Standards | FDA, HACCP, GMP, CE compliant |
6. Working Principle
The operation of a 4000L SS food grade storage tank follows a structured industrial workflow:
Step 1: Filling Process
Liquid food is transferred into the tank through sanitary pipelines after processing or pasteurization.
Step 2: Storage Stage
The tank maintains controlled conditions:
·
Temperature stability
·
·
Hygienic sealed environment
·
·
Oxygen exposure control
·
Step 3: Mixing (Optional)
If equipped with agitator:
·
Maintains uniform product distribution
·
·
Prevents sediment formation
·
·
Ensures product consistency
·
Step 4: Discharge Process
The product is discharged via bottom valve into:
·
Filling machines
·
·
Packaging lines
·
·
Secondary processing systems
·
Step 5: Cleaning Cycle
CIP system performs automatic cleaning without disassembly.
7. Advantages of 4000L SS Food Grade Storage Tank
7.1 High Hygiene Standard
Stainless steel prevents microbial growth and contamination.
7.2 Excellent Corrosion Resistance
Suitable for acidic, salty, and sugar-rich liquids.
7.3 Long Service Life
Durability exceeds 10–20 years under industrial use.
7.4 Temperature Stability
Maintains product quality during storage.
7.5 Easy Maintenance
Compatible with automated CIP Cleaning Systems.
7.6 High Production Efficiency
Supports continuous industrial processing.
7.7 Flexible Integration
Works with:
·
Pasteurizers
·
·
Homogenizers
·
·
Filling machines
·
·
Mixing systems
·
8. Applications Across Industries
8.1 Fruit Juice Industry
Used for storing orange juice, apple juice, mango juice, and concentrate products.
8.2 Dairy Industry
Stores milk, cream, yogurt base, and flavored dairy products.
8.3 Sauce Manufacturing
Used for ketchup, mayonnaise, soy sauce, and condiments.
8.4 Beverage Industry
Stores ready-to-drink beverages and functional drinks.
8.5 Food Processing Industry
Used for edible oils, syrups, and liquid ingredients.
8.6 Catering Industry
Bulk preparation and storage of liquid food materials.
9. Material Comparison: SS304 vs SS316
Feature
SS304
SS316
|
|
|
Corrosion Resistance | High | Very High |
Acid Resistance | Medium | Excellent |
Durability | High | Very High |
Cost | Lower | Higher |
Application | Standard food liquids | High-acid products |
10. Structural Design Features
·
Cylindrical tank body for even pressure distribution
·
·
Conical bottom for complete drainage
·
·
Reinforced support legs
·
·
Top manhole for inspection
·
·
Side manhole optional for cleaning
·
·
External insulation layer for thermal efficiency
·
11. Cleaning and Maintenance (CIP System)
Cleaning Steps:
00001.
Pre-rinse with warm water
00002.
00003.
Alkali cleaning for organic residues
00004.
00005.
Acid cleaning for mineral deposits
00006.
00007.
Final rinse with clean water
00008.
00009.
Steam sterilization (optional)
00010.
Maintenance Schedule:
·
Daily valve inspection
·
·
Weekly sealing check
·
·
Monthly agitator maintenance
·
·
Annual internal polishing
·
12. Safety and Compliance Standards
The tank meets global food safety requirements:
·
FDA Food Contact Standards
·
·
HACCP Safety System
·
·
GMP Manufacturing Standards
·
·
CE Mechanical Safety Certification
·
Safety Features:
·
Pressure relief valve
·
·
Overflow protection system
·
·
Temperature sensors
·
·
Anti-static grounding system
·
·
Emergency shut-off control
·
13. Comparison with Other Storage Solutions
Type
Hygiene
Durability
Cost
Performance
|
|
|
|
|
Plastic Tank | Low | Low | Low | Poor |
Carbon Steel Tank | Medium | Medium | Medium | Moderate |
SS304 Tank | High | High | Medium | High |
SS316 Tank | Very High | Very High | High | Excellent |
4000L SS Tank | Industrial Grade | Industrial Grade | Medium-High | Excellent |
14. Installation Requirements
·
Flat reinforced concrete foundation
·
·
Proper drainage system
·
·
Electrical supply for automation
·
·
Steam/glycol connection (if applicable)
·
·
Sanitary pipeline integration
·
Installation must ensure:
·
Level stability
·
·
Hygienic sealing
·
·
Easy maintenance access
·
15. Operational Guidelines
·
Maintain 70%–90% filling level
·
·
Use low-speed agitation only
·
·
Avoid long-term stagnant storage
·
·
Monitor temperature continuously
·
·
Ensure daily hygiene inspection
·
16. Energy Efficiency Optimization
·
High-quality insulation reduces heat loss
·
·
Low-power agitator motors
·
·
Efficient CIP water usage
·
·
Smart temperature control systems
·
·
Reduced operational energy consumption
·
17. Market Trends and Industry Outlook
The demand for food grade stainless steel storage tanks is increasing due to:
·
Growth in global food processing industry
·
·
Rising demand for packaged beverages
·
·
Increased hygiene regulations
·
·
Expansion of dairy and juice production
·
·
Automation in food factories
·
Future Trends:
·
IoT smart storage systems
·
·
AI-based monitoring
·
·
Fully automated CIP systems
·
·
Energy-efficient tank designs
·
·
Modular scalable tank systems
·
18. Purchasing Guide
When selecting a 4000L SS food grade storage tank, consider:
·
Material grade (SS304 vs SS316)
·
·
Product type compatibility
·
·
Heating/cooling requirements
·
·
Agitation system needs
·
·
Cleaning system integration
·
·
Certification compliance
·
19. Conclusion
The 4000L Food Grade Stainless Steel Storage Tank is a critical component in modern food and beverage processing systems. With its large capacity, hygienic design, corrosion resistance, temperature control options, and automation compatibility, it ensures safe, stable, and efficient storage of liquid food products.
Its versatility across juice, dairy, sauce, and beverage industries makes it an indispensable asset for medium and large-scale production facilities. As global demand for safe and standardized food production continues to grow, this type of tank will remain a core industrial solution for modern food manufacturing systems.
+86 29-87031531
Phone
